As valves used in construction facilities for cooling and heating, they comprise automatic flow control valves (per household, per partment building), constant flow temperature control valves, differential ressure flow control valves, and differential pressure control valves
-
Applicable fluid:cold/hot water
Connection method:Inlet: KS PT Screw (inner diameter)
Outlet: KS PF Screw (outer diameter)
texture:BODY: copper and copper alloy
Maximum applied pressure:1.0 MPaMaximum operating temperature:120 yenMaximum differential pressure:0.6 MPaView details -
Applicable fluid:cold/hot water
Differential pressure range:0.016MPa
Applicable fluid temperature:Below 110℃
texture:Body: CAC303
Disc, Seat : CAC303
Diaphragm: EPDMView details -
Applicable fluid:cold/hot water
Differential pressure range:0.005~0.03MPa
Applicable fluid temperature:Below 110℃
texture:Body: CAC303
Disc, Seat : CAC303
Diaphragm: EPDMView details -
Applicable fluid:cold/hot water
Differential pressure range:0.03~0.4MPa (0.06~0.4MPa 200HF/250HF)
Applicable fluid temperature:5℃~120℃ or less
Connection method:FLANGE
texture:Body: GCD450
Disc : CAC406
Diaphragm: EPDMView details -
Applicable fluid:cold/hot water
Differential pressure range:0.03~0.3MPa
Applicable fluid temperature:5℃~120℃ or less
Connection method:SCREW / UNION
texture:Body: CAC303
Disc: C3604
Diaphragm: EPDMView details -
Applicable fluid:cold/hot water
Differential pressure range:0.05~0.5MPa
Applicable fluid temperature:120℃ or less
Connection method:KS 20K RF FLANGE
texture:Main body: SCPH2
disc, seat: STS
diaphragm EPDM
Body pressure test:Water pressure 1.5 times the flange applied pressureView details -
Applicable fluid:cold/hot water
Differential pressure range:0.03~0.3MPa
Applicable fluid temperature:120℃ or less
Connection method:KS 10K RF FLANGE
texture:Body: GC200
Disc, Seat : STS
Diaphragm EPDM
Body pressure test:Water pressure 1.5 times the flange applied pressureView details -
Chất lỏng áp dụng:nước lạnh / nóng
Phạm vi áp suất chênh lệch:0,01 ~ 0,18MPa, 0,15 ~ 0,5MPa
Nhiệt độ chất lỏng áp dụng:120 ℃ trở xuống
Phương thức kết nối:KÍCH THƯỚC RF KS 20K
kết cấu:Thân:
Đĩa GC200 , Ghế: CAC406
Màng: EPDM
Kiểm tra áp suất cơ thể:Áp lực nước 3.0MPaView details -
Chất lỏng áp dụng:nước lạnh / nóng
Phạm vi áp suất chênh lệch:0,01 đến 0,18 MPa, 0,15 đến 0,5 MPa
Nhiệt độ chất lỏng áp dụng:120 ℃ trở xuống
Phương thức kết nối:KÍCH THƯỚC RF 10K
kết cấu:Thân:
Đĩa GC200 , Ghế: CAC406
Màng: EPDM
Kiểm tra áp suất cơ thể:Áp lực nước 1.5MPaView details -
Applicable fluid:cold/hot water
Differential pressure range:0.05~0.3MPa
Applicable fluid temperature:120℃ or less
Connection method:KS 10K RF FLANGE
texture:Body: GC200
Disc, Seat: CAC406
Diaphragm: EPDM
Body pressure test:Water pressure 1.5MPaView details -
Applicable fluid:cold/hot water
Differential pressure range:0.05 to 0.3 MPa, 0.3 to 0.5 MPa
Applicable fluid temperature:120℃ or less
Connection method:KS 20K RF FLANGE
texture:Body: SCPH2
Disc, Seat : STS
Diaphragm: EPDM
Body pressure test:Water pressure 3.0MPaView details -
Applicable fluid:cold/hot water
Differential pressure range:0.03~0.7MPa
Applicable fluid temperature:300℃ or less
Connection method:KS 10K FF FLANGE
texture:Main body: SPPS Main
part: STS
Body pressure test:Water pressure 1.5MPaView details -
Applicable fluid:cold/hot water
Differential pressure range:0.02~0.15MPa, 0.03~0.4MPa
Applicable fluid temperature:120℃ or less
Connection method:KS PT SCREW
texture:Main body: C3604 Main
part: STS
Body pressure test:Water pressure 1.5MPaView details -
Applicable fluid:cold/hot water
Differential pressure range:0.03~0.4MPa
Connection method:Inlet: PT Screw (inner diameter) / PF Screw (outer diameter)
Outlet: PT Screw (inner diameter) / PF Screw (outer diameter)
texture:Body: KSD 6024 CAC 303
Disc: KSD 5101 C3603BE
Diaphragm: EPDM
Body pressure test:Water pressure 1.5 Mpa (1500 KPa)flow deviation:5% of set flowfluid temperature:5-120℃ambient temperature:-20 ~ 65℃View details -
Applicable fluid:cold/hot water
Differential pressure range:0.05~0.5MPa
Applicable fluid temperature:120℃ or less
Connection method:KS 20K RF FLANGE
texture:Main body: SCPH2
disc, seat: STS
diaphragm EPDM
Body pressure test:Water pressure 1.5 times the flange applied pressureView details -
Applicable fluid:cold/hot water
Differential pressure range:0.03~0.3MPa
Applicable fluid temperature:120℃ or less
Connection method:KS 10K RF FLANGE
texture:Body: GC200
Disc, Seat : STS
Diaphragm EPDM
Body pressure test:Water pressure 1.5 times the flange applied pressureView details
