Applicable fluid:cold/hot water
Applied pressure:1.0Mpa or less
Applicable fluid temperature:5-80℃
Connection method:KS PT SCREW
texture:Body: GC200 Disc, Seat
: EPDM, STS
Body pressure test:Water pressure 1.5Mpa
Air Vent YAC-4
As an air vent valve for liquid, it automatically discharges remaining air from pipelines
and air from sealed tanks, thereby allowing for smooth flow of fluid.
Features
• Large discharge capacity covers up to 10~20 kgf/cm2g.
• Flexible disc structure for smooth & subtle operation.
• NBR-based seat features outstanding level of air tightness.
• Easy repair & inspections manufactured.
Applicable fluid:cold/hot water
Applied pressure:1.0Mpa or less
Applicable fluid temperature:5-80℃
Connection method:KS PT SCREW (Female)
texture:Body: CAC303 Disc, Seat
: EPDM, STS
Body pressure test:Water pressure 1.5Mpa
Applicable fluid:cold/hot water
Applied pressure:1.0Mpa or less
Applicable fluid temperature:5-80℃
Connection method:KS PT SCREW (Female)
texture:Body: CAC303 Disc, Seat
: EPDM, STS
Body pressure test:Water pressure 1.5Mpa
Applicable fluid:cold/hot water
Applied pressure:1.0Mpa or less
Applicable fluid temperature:5~100℃
Connection method:KS PT SCREW
texture:Body: C3771 Disc, Seat
: NBR, C3604
Body pressure test:Water pressure 1.5Mpa
