Khi được lắp đặt ở phía đầu vào của máy bơm của bể nước ngầm, Chân van YVF-1 này thích hợp để ngăn dòng chảy ngược của chất lỏng.
Foot Valve YVF-1
Chất lỏng áp dụng:nước
Áp suất hoạt động tối đa:1.0Mpa trở xuống
Nhiệt độ chất lỏng áp dụng:80 ℃ trở xuống
Phương thức kết nối:KÍCH THƯỚC RF 10K
kết cấu:Nội dung:
Đĩa GC200 ,Ghế : NBR, CAC406
Màn hình: STS
Kiểm tra áp suất cơ thể:Áp lực nước 2.0Mpa
Applicable fluid:Sat, Steam, Superheat Steam, Oil, Water, Gas
working pressure:1.0, 2.0, 3.0Mpa
Applicable fluid temperature:250℃ (order over 250℃ separately)
texture:Body : CAC304, STS, SPPS, SCPH2, GCD
SLEEVE : CAC304, STS, SC480
PACKING : Grafoil (SI NO.800)
View details
Applicable fluid:Drinking water, fresh water, industrial water, agricultural water
Applied pressure:1.0Mpa or less
Minimum differential pressure before and after the valve:0.034Mpa
Applicable fluid temperature:5~80℃
Connection method:KS PT SCREW
texture:Body: GC200 Disc, Seat : NBR, CAC406
Body pressure test:Water pressure 1.5Mpa
View details
Applicable fluid:Sat, Steam, Superheat Steam, Oil, Water, Gas
working pressure:1.0, 2.0, 3.0Mpa
Applicable fluid temperature:250℃ (order over 250℃ separately)
texture:Body : CAC304, STS, SPPS, SCPH2, GCD
SLEEVE : CAC304, STS, SC480
PACKING : Grafoil (SG NO.800)
View details
Applicable fluid:Sat, Steam, Superheat Steam, Oil, Water, Gas
working pressure:1.0, 2.0, 3.0Mpa
Applicable fluid temperature:250℃ (order over 250℃ separately)
texture:Body : CAC304, STS, SPPS, SCPH2, GCD
SLEEVE : CAC304, STS, SC480
PACKING : Grafoil (SI NO.800)
View details
View details
Applicable fluid:water
1st applied pressure:Up to 1.0 MPa
2nd applied pressure:0.05~070MPa
Applicable fluid temperature:5~80℃ or less
Connection method:15A~25A : KS PT SCREW
32A~150A : KS 10K FF FLANGE
texture:Body: GC200
Disc, Seat : NBR, CAC406
Diaphragm: NBR
Body pressure test:Water pressure 1.5MPa
View details
Applicable fluid:water, liquid
Applied pressure:2.0Mpa or less
fluid temperature:120℃ or less
Connection method:KS 20F RF FLANGE
texture:Body: GCD450
Disc, Seat : EPDM, CAC406
GASKET: NBR, EPDM
Body pressure test:3.0Mpa
View details
Applicable fluid:Sat, Steam, Superheat Steam, Oil, Water, Gas
working pressure:1.0, 2.0, 3.0Mpa
Applicable fluid temperature:250℃ (order over 250℃ separately)
texture:Body : CAC304, STS, SPPS, SCPH2, GCD
SLEEVE : CAC304, STS, SC480
PACKING : Teflon + Grafoil (SI NO.800)
View details
Applicable fluid:water, gas
1st applied pressure:Up to 2.0 MPa
2nd applied pressure:0.05 to 069
MPa 0.69 to 1.4 MPa
Minimum differential pressure before and after the valve:0.05Mpa
Maximum decompression ratio:10:00 am
Applicable fluid temperature:5~80℃ or less
Connection method:KS 20K RF FLANGE
texture:Body: SCPH2
Disc, Seat : NBR, STS
Diaphragm: NBR
Body pressure test:Water pressure 1.5 times of flange applied pressure
View details
Applicable fluid:water, liquid
Applied pressure:1.0Mpa or less
fluid temperature:80℃ or less
Connection method:KS 10F FF FLANGE
texture:Body: GC200
Disc, Seat : EPDM, CAC406
GASKET: NBR, EPDM
Body pressure test:1.5Mpa
View details
Applicable fluid:water, liquid
Applied pressure:3.0Mpa or less
fluid temperature:120℃ or less
Connection method:KS 30F RF FLANGE
texture:Main body: SCPH2
disc, sheet: EPDM, CAC406
GASKET: NBR, EPDM
Body pressure test:4.5Mpa
View details
